Your door: R-10.25 · 8' x 7' · Natural Oak · TOB Black · Open band
Garage Doors
Wood Band by Modern Decor - Woodgrain Inlay Aluminum Composite (ACM) Garage Door
Modern Decor Wood Band — a black aluminium composite frame around a band of European woodgrain steel in every section. The smoked-glass layout with wood in place of the glass. Insulated to R-10.25 or R-17.65.
How to measure
Headroom is the space between the top of the finished opening and the ceiling — or, if something hangs lower, the space to that: a pipe, a beam, a light, the opener rail. Measure at the tightest point across the whole opening.
Two more numbers help us confirm the fit: side room, from each side of the opening to the wall (about 5″ each side for a standard track), and backroom, the depth straight back into the garage (your door height plus about 18″).
Enter your headroom to see which tracks fit.
Financing available through Synchrony Bank · Promotional/sale-priced items are not eligible for financing. Learn more →
The Wood Band takes the smoked-glass composition and swaps the dark tint for wood: 4" black composite side frames and a 4" band along the foot of every section, with European woodgrain steel filling the opening above. Four sections, four bands — the grain runs the width of the door and the composite holds it like a picture frame.
- Layout: open band, or closed with a 4" composite rail across the very top of the door
- Band height: 17" in a 7-ft door's 21" sections, 20" in an 8-ft door's 24" sections; the closed layout's rail shortens the top band alone, to 13" or 16"
- Woodgrain: Erkado steel — Natural Oak, Walnut, Swamp Oak or Black
- Composite: 4 mm ALPOLIC in TOB Black, routed and folded, 5/8" proud of the door face
- 16-ft doors carry a 4" composite divider at the centre, so each band is a single sheet of woodgrain rather than a seam in open field
- Base door: insulated steel, R-10.25 or R-17.65
- Sizes: 8x7, 8x8, 9x7, 9x8, 16x7, 16x8
- Includes the heavy-duty hardware upgrade the added panel weight requires
Every combination carries an exact installed price, and every combination is photographed: each finish pairing is its own render, not one picture recoloured.
Wood Band — a woodgrain inlay in a composite frame
Our smoked-glass composition with wood where the glass would be. Every section is framed in black aluminium composite — 4″ up each side and a 4″ band along the foot — and the opening above it is filled with European woodgrain steel. Four sections, four bands of grain running the width of the door.
The two layouts
- Open band — side frames and a bottom band only, so each band of woodgrain runs up to the section joint above it.
- Closed band — a 4″ composite rail across the very top of each section as well, which closes the framing on all four sides.
Band height
- 7-ft doors (21″ sections): 17″ of woodgrain, or 13″ with the top rail.
- 8-ft doors (24″ sections): 20″ of woodgrain, or 16″ with the top rail.
What you choose
- Woodgrain color: Natural Oak, Walnut, Swamp Oak or Black — the same finishes as our steel entry doors.
- Composite color: TOB Black.
- Layout: open band or closed band.
- Insulation: R-10.25 or R-17.65.
- Size: 8×7, 8×8, 9×7, 9×8, 16×7 or 16×8.
16-ft doors
Our woodgrain steel comes up to 9 ft wide, so a 16-ft band cannot be one sheet. Rather than drop a seam into open grain, the door carries a 4″ composite divider at the centre of every section and each half of the band is a single sheet.
Glass
None. The Wood Band is the wood version of the layout; the glazed version of the same idea is the Onyx.
Photography
Every combination is photographed: 48 fronts, one for each woodgrain finish at each size with the band open and closed, so the choice you make is the door you see.
The composite frame is described in the Construction & Materials tab; the woodgrain skin is in Woodgrain Steel Skin.
How an ACM door is built
An ACM door starts as a real insulated steel sectional door and is clad in 4 mm ALPOLIC aluminium composite. Every face is routed and folded from a single sheet, so the panel you see has no applied edge trim, and it stands 5/8″ proud of the door face. The leaf is four sections of 2″ thickness, and the section joints stay visible as they do on any sectional door — the pattern is applied to a door, not printed on a slab.
Base door and insulation
- Base: insulated steel sectional door, R-10.25 or R-17.65.
- Hardware: the heavy-duty hardware upgrade the added panel weight requires is included.
- Sections: four per door — 21″ on a 7-ft door, 24″ on an 8-ft door.
Colors
ACM is its own finish family: composite is never finished in the woodgrain steel colors, and steel is never finished in the composite ones. On the two hybrid doors — the Duet and the Wood Band — both materials sit on the same leaf, and each keeps its own palette.
- TOB Black
- BLX Black
- MRO Anthracite Grey
- Mica Grey
- BSX Metallic Silver
- SAW White
Glass
Glazed ACM designs use 3 mm dark tint glass, recessed to the base plane so the ACM stays the outermost surface. Panes are used at their stock cut sizes and are never re-cut to fit a layout — where a width will not divide exactly, the design absorbs it in the ACM, not in the glass.
Panel gaps and proportion
The reveal between panels runs 3/8″, 1/2″, 3/4″ or 1″. It is chosen by the layout for the proportion of your door rather than offered as a separate choice, which is also why panel widths within a design are not always equal.
Sizes
8×7, 8×8, 9×7, 9×8, 16×7 and 16×8. Every repeating ACM design — Slate, Staggered, Cadence, Gradia, Meridian, Linea, Mirage — is offered in all six, and so are the Onyx in both of its pane arrangements and the two hybrids, the Duet and the Wood Band. Only the Half View lists its own sizes under Model Specifications instead: its bays are 16-ft.
About the renderings on this page
Please note: Visual renderings are solely for visualization purposes — they do not reflect exact colors, dimensions or layouts. For an exact idea of how the door panels and glass will be spaced, sized and laid out, please speak to a sales rep and request a dimensional breakdown or tech sheet.
How this door is built
A three-layer insulated steel sectional door, skinned by us in European woodgrain steel (on the Duet and the Wood Band, in the field the composite leaves open) — the same 0.6 mm overlay steel, in the same finishes, as our European steel entry doors. That is the point of the line: the garage door and the front door can be ordered in one finish and read as one elevation.
Insulation and sections
- Insulation: R-10.25 or R-17.65.
- Sections: four per door — 21″ on a 7-ft door, 24″ on an 8-ft door.
Colors
Natural Oak, Walnut, Swamp Oak and Black — matched to our steel entry doors.
Glass
The Duet and the Wood Band carry no glass at all. Everywhere else on these lines glazing is dark tint throughout. The glass is never sunk below the steel: on a flush design the pane sits marginally proud of the skin, and on a framed design it is held behind the frame face like a window. Where two lites meet you will see a fine joint line rather than one continuous sheet.
Doors wider than 9 feet
Our steel skins come up to 9 ft wide, so a 16-ft door carries a vertical seam in the skin. It is placed deliberately — at a glass edge or another natural break in the design — never dropped into the middle of a plain field.
Sizes
8×7, 8×8, 9×7, 9×8, 16×7 and 16×8.
About the renderings on this page
Please note: Visual renderings are solely for visualization purposes — they do not reflect exact colors, dimensions or layouts. For an exact idea of how the door panels and glass will be spaced, sized and laid out, please speak to a sales rep and request a dimensional breakdown or tech sheet.
Below are specifications of all Garage Door Motor Options
LM L979M WIRELESS KEYPAD MAX:
- Compatible with most major brands of Garage Door Openers manufactured after January 1997.
- Easier programming with automatic frequency detection.
- Program in myQ app and access features (PIN codes, set schedules, notifications, access history and battery status) with Security+ 3.0 Garage Door Openers.
- Users can program temporary PIN codes for friends and service people.
- Closes the Garage Door instantly with one press activation
LM 878 Max Wireless Keypad
- Features Security+ 2.0® rolling code technology
- One-button-to-close feature (works with all LiftMaster garage door openers manufactured since 2006)
- Temporary password option, Program code directly from keypad
- Backlit keypad, Includes 9V battery
- Compatible with all LiftMaster garage door openers manufactured since January 1993
KSWKP WIRELESS KEYPAD KWIKSET
- Compatible with Kwikset FLEX openers
- Open or close the garage door without using a remote
- Includes 9V battery
LM 893 Max 3-Button Remote Control
- Controls up to three garage door openers, gates or myQ® enabled light devices
- Features Security+2.0 rolling code technology
- Compatible with all LiftMaster garage door openers manufactured since January 1993, and all 315MHz LiftMaster and ELITE gate operators
LM L932M 2 BUTTON KEYCHAIN MAX
- Compatible with up to three Garage Door Openers, Gate Operators, or Commercial Door Operators manufactured by LiftMaster after 1997.
- Extra-long range for extended reach and reliable operation.
- Easier programming with automatic frequency detection.
- Program in myQ app and access features (naming, notifications and access history) with Security+ 3.0 and Security+ 2.0 Garage Door Openers.
- Fits on a keychain, backpack or in a purse or pocket
KSTX3 FLEX REMOTE 3 BUTTON
- Compatible with Kwikset FLEX openers
- Controls up to three Garage doors
- Flexible to use as visor mount or keychain remote
- HomeLink compatible
- 315MHz frequency
- Powered by 2032 coin cell battery (included)
KSTX1 FLEX REMOTE 1 BUTTON
- Compatible with Kwikset FLEX openers
- Controls one garage door
- Flexible to use as visor mount or keychain remote
- HomeLink compatible
- 315MHz frequency
- Powered by 2032 coin cell battery (included)
Installation
Every Modern Decor garage door can be installed by our own crews. Installation is quoted separately and is never included in a listed price — the price on this page is for the door as configured, and your written quote itemises the rest.
Sold and installed by Modern Decor Supply LLC, NJ Home Improvement Contractor Reg. #13VH13488900, from our Hackensack, NJ showroom — serving New Jersey, New York, Pennsylvania and Connecticut.
Before you order
- Measure the opening, not the old door. The How to Measure Garage Opening tab shows exactly what to measure.
- Check your headroom and jambs. Track and headroom options — standard radius, low-headroom, high-lift, vertical-lift and follow-the-roof-pitch — are chosen in the configurator above, and each option states the headroom it needs.
- Decide on the opener while you are there: motors, keypads and remotes are all quoted with the door.
Lead time
These doors are made to order. The production time for your exact configuration is confirmed in writing with your quote — ask us and we will tell you what we are running the week you order, rather than publishing a number that drifts.
